Mud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling Cementing

Model Number : Drilling Hose

Certification : ISO9001:2008

Place of Origin : China

MOQ : 1 Meter

Price : US$ 35/Meter

Payment Terms : L/C, T/T

Capability : Rubber Oil Hose

Color : Red/Black

Product Name : Rotary Drilling Cementing Hose

Application : Oil Drilling, Mud Drilling, Pump Rotary Drilling

Outer Rubber : Chloroprene Rubber (Cr Fabricated)

Material : Nitrile Rubber

Contact Now

Rotary Drilling Hose

Drilling hose(rotary hose)made according to API 7K spec, applies for flexible hose connection between the top of oil drilling stand pipe and vertical moved swivel joint in well drilling, well cementing, work-over and down-hole servicing operation. drilling hose is also used to adjust the installation mistake between drilling pipe line and stand pipe to avoid shake, sometimes to transfer high pressure oil and water base mud with the lowest aniline point of 60°C from the swivel pipe in high pressure, and down-hole operation high medium such as water, oil etc, drilling rotary hose can be used for prefect work too.


Inner Tube: principally NBR constructed, featuring oil-resistant, abrasion resistant,acid and alkali resistant.
Reinforcement: 2-8 layers spiraled by single high-strength steel wire and rubber as abinder to make the lavers into one complete and sound construction.
Cover: primarily CR fabricated, featuring oil resistant, abrasion-resistant, weatherproof and anti-aging.
Working Temperature: It is used to carry slurry, water at environmental temperature of-30°C to +82°C , and other fluids.

Mud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling CementingMud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling CementingMud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling CementingMud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling Cementing

Application:
The vibrator hose is applied for oil driling, the drilling mud in the delivery system between the top of riser with the vertical movement of the faucet may be connected to flexible hose and applied to theine between pump and the drilling riser for adjusting misalignment, to facilitate connection andvibration isolation. It is applied for oil fields, cementing, repairing, geological explorations, small drilling machine, andwater conveyance at coal excavations.

lt is also applied to a large number of transport under high pressure from the pump rotary drilling equipment and a minimum point of water-based or oil-based mud 66°C and can anti-corrosive hydrogen sulfide, oilfield down hole conveying water, oil, mud high media.

Mud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling Cementing

Size Chart:

Vibrator Hose Technical Specification
Table 1:Grade A
I.D O.D W.P Proof Pressure P.P Min B.R Weight Coupling Thread
mm inch mm Mpa Psi Mpa Psi mm kg/m LP
38 1 1/2 51 11 1500 22 3000 560 2.19 2
51 2 65 11 1500 22 3000 900 3.03 2 1/2
64 2 1/2 78 11 1500 22 3000 1200 3.95 3
Table 2:Grade B
I.D O.D W.P Proof Pressure P.P Min B.R Weight Coupling Thread
mm inch mm Mpa Psi Mpa Psi mm kg/m LP
38 1 1/2 52 14 2000 28 4000 560 2.39 2
51 2 66 14 2000 28 4000 900 3.25 2 1/2
64 2 1/2 79 14 2000 28 4000 1200 4.37 3
76 3 98 14 2000 28 4000 1200 7.76 4
89 3 1/2 113 14 2000 28 4000 1300 9.95 4
102 4 127 14 2000 28 4000 1400 12.43 5
127 5 113 14 2000 28 4000 1500 15.25 6
Table 3:Grade C
I.D O.D W.P Proof Pressure P.P Min B.R Weight Coupling Thread
mm inch mm Mpa Psi Mpa Psi mm kg/m LP
38 1 1/2 55 28 4000 56 8000 560 3.65 2
51 2 69 28 4000 56 8000 900 5.15 2 1/2
64 2 1/2 88 28 4000 56 8000 1200 7.86 3
76 3 105 28 4000 56 8000 1200 13.12 4
89 3 1/2 121 28 4000 56 8000 1300 16.79 4
102 4 137 28 4000 56 8000 1400 21.70 5
127 5 164 28 4000 56 8000 1500 28.46 6
Table 4:Grade D
l.D O.D W.P Proof Pressure P.P Min B.R Weight Coupling Thread
mm inch mm Mpa Psi Mpa Psi mm kg/m LP
51 2 73 35 5000 70 10000 900 6.46 2 1/2
64 2 1/2 91 35 5000 70 10000 1200 10.75 3
76 3 107 35 5000 70 10000 1200 14.35 4
89 3 1/2 123 35 5000 70 10000 1300 18.70 4
102 4 139 35 5000 70 10000 1400 23.16 5
127 5 164 35 5000 70 10000 1500 38.00 6
Table 5:Grade E
I.D O.D W.P Proof Pressure P.P Min B.R Weight Coupling Thread
mm inch mm Mpa Psi Mpa Psi mm kg/m LP
51 2 80 52 7500 104 15000 1000 10.37 2 1/2
64 2 1/2 101 52 7500 104 15000 1200 17.88 3
76 3 120 52 7500 104 15000 1200 24.45 4
89 3 1/2 135 52 7500 104 15000 1300 29.33 4
102 4 148 52 7500 104 15000 1400 34.24 5
127 5 189 52 7500 104 15000 1500 55.39 6

Mud Cement Slurry Rubber Industrial Flexible Hose For Well Drilling Cementing
